Panzerstahl zum Schutz des Menschen
Weltklasse-Panzerstahl für Ihre Sicherheit
Protection 500 ist ein fortschrittlicher Panzerstahl, der Sie vor Explosionen und direkte Einschläge schützt.
Protection 500 ist das Ergebnis langjähriger Produktentwicklung und Feinabstimmung. Es hat sich sowohl bei zivilen als auch bei militärischen Anwendungen, bei denen es auf die menschliche Sicherheit ankommt, als großartige Lösung erwiesen.
Protection 500 sheets and plates are bullet proof tested and approved in compliance with international standards, such as:
- EN 1522 / 1063 - VPAM 2007 - Stanag 4569 - MIL-DTL-4600 / 12560
Testing accorrding to other standards is possible, upon request. Ask your Specialty Steel contact person for more information.
Chemical composition (max. % ladle analysis) thickness 2,5 - 40,0 mm
| C | Si | Mn | P | S | Cr | Ni | Mo | B |
|---|---|---|---|---|---|---|---|---|
| 0,30 | 0,70 | 1,70 | 0,030 | 0,015 | 1,50 | 0,80 | 0,50 | 0,004 |
Typical mechanical properties thickness 2,5 - 40,0 mm
Yield strengthRp 0,2 N/mm² |
Tensile strengthRm N/mm² |
ElongationA5 % |
Impact Charpy-V-40°C Kv Joule |
Hardness rangeHBW |
CEV |
|---|---|---|---|---|---|
| 1250 | 1600 | 8 | 20 | 480-560 | 0,64 |
Technical specifications
Class |
Testthickness |
Weapon |
Calibre |
Bullet |
Bulletweight |
Shootingdistance |
Bullet speedV2,5 (m/s) |
|---|---|---|---|---|---|---|---|
| EN 1522 FB3 | 2,5 mm | Revolver | 357 Mag. | Fulljacket, coned bullet, soft core | 10,2 g | 5 m | 430 (± 10 m/s) |
| EN 1522 FB4 | 3,0 mm | Revolver | 44 Rem. Mag. | Fulljacket, flat nose, soft core | 15,6 g | 5 m | 440 (± 10 m/s) |
| 4,2 mm | Rifle | 7,62 x 39 mm | AK-47 M43 | 8,0 g | 10 m | 720 (± 10 m/s) | |
| EN 1522 FB5 | 6,0 mm | Rifle | 5,56 x 45 mm | SS109 M855) | 4,0 g | 10 m | 950 (± 10 m/s) |
| EN1522 FB6 | 6,0 mm | Rifle | 7,62 x 51 mm | M80 Nato Ball | 9,5 g | 10 m | 830 (± 10 m/s) |
| EN 1522 FB7 | 14,0 mm | Rifle | 7,62 x 51 mm | P80 Nato AP | 9,5 g | 10 m | 820 (± 10 m/s) |
| Stanag 4569 Lev. 1 | 6,0 mm | Rifle | 7,62 x 51 mm | M80 Nato Ball | 9,5 g | 30 m | 833 (± 20 m/s) |
| Stanag 4569 Lev. 1 | 6,0 mm | Rifle | 5,56 x 45 mm | SS109 (M855) | 4,0 g | 30 m | 900 (± 20 m/s) |
| Stanag 4569 Lev. 1 | 9,0 mm | Rifle | 5,56 x 45 mm | M193 | 3,5 g | 30 m | 937 (± 20 m/s) |
| Stanag 4569 Lev. 2 | 12,0 mm | Rifle | 7,62 x 39 mm | API BZ | 7,7 g | 30 m | 695 (± 20 m/s) |
| Stanag 4569 Lev. 3 | 24,0 mm | Rifle | 7,62 x 51 mm | AP (WC core) | 8,4 g | 30 m | 930 (± 20 m/s) |
| Stanag 4569 Lev. 3 | 16,0 mm | Rifle | 7,62 x 54R mm | B32 API | 10,3 g | 30 m | 854 (± 20 m/s) |
Available from stock
3,0 x 1250 x 3000 mm 3,0 x 1500 x 3000 mm 4,2 x 1500 x 3000 mm 5,0 x 1500 x 3000 mm 6,5 x 1500 x 3000 mm
Thicknesses > 5,0 and ≤ 40,0 mm and other dimensions available from mill stock and/or from new production with short lead times.
Ask your Specialty Steel contact person for detailed information.
Tolerances
EN 10029 (plate) or EN 10051 (sheet). Flatness acc. to EN 10029 Class N steeltype H. Thickness acc. EN 10029 Class C.
| Thickness (mm) | Tolerances (mm) |
|---|---|
| 3,0 - 4,0 | - 0,0 + 0,35 |
| 5,0 - 6,0 | - 0,0 + 0,70 |
| 7.0 - 9,0 | - 0,0 + 0,90 |
| 10,0 - 13,0 | - 0,0 + 1,00 |
| > 13,0 | - 0,0 - + 1,10 |
